Video Input and Transmission
Up to 4/8 IP cameras (max. incoming bandwidth: 50 Mbps), Live view of the connected camera at up to 4 MP resolution
Compression and Recording
H.264, H.265, H.264+, and H.265+ compression. Full channel recording at up to 4 MP resolution
Video Output
HDMI/VGA output with up to 1920 × 1080 resolution
Storage and Playback
1 SATA interface for HDD with up to 6 TB capacity
Up to 4/8-ch synchronous playback
Smart search for efficient playback
Smart Function
Supports line crossing and intrusion VCA (Video Content Analytics) events for IP cameras
Network & Ethernet Access
Hik-Connect for easy network management One 100M Ethernet network interface
Wi-Fi Features
Provides Wi-Fi function. Up to 16 terminals, including mobile phone and laptop, can access NVR via Wi-Fi
Incoming/outgoing
Up to 64 channel
bandwidth
50/40 Mbps
HDMI/VGA output
1-ch, resolution: 1920 × 1080/60Hz, 1280 × 1024/60Hz,
Audio output
1-ch, RCA (linear, 1 KΩ)
Recording resolution
4 M/3 M/1080p/1.3 M/720p
Synchronous playback
4-ch,8 ch, 16 ch.,32 ch
Capacity
2-ch@1080p / 1-ch@4 MP
SATA Interface
1 SATA interface
Up to 8 TB x 2 capacity for each disk
Frequency band
2.4 GHz
Antenna structure
2 × 2MIMO
Transmission speed
144 Mbps
Transmission standard
IEEE 802.11b/g/n
Network interface
1, RJ45 10/100M Ethernet interface
USB interface
Rear panel: 2 × USB 2.0
Power supply
12 VDC
