Signal input
HDTVI/HDCVI/AHD/CVBS
Camera input
up to 128 input
Video input
8 MP/5 MP/4 MP HDTVI video input and live view
Signal
max. 800m for 1080p and 1200m for 720p HDTVI signal
Compression Format
H.264
Operating System
Embedded Linux
Input
Up to 128 input
Output
128 X BNC Main out, 1 X VGA & 1 X HDMI Audio Input
Resolution
NTSC:D1(704X576), HD1(704X288), CIF353X288) PAL:D1(704X480), HD1(704X240), CIF353X240)
Frames
200/240FPS @ HD1, 100/120FPS @ D1
Recording Mode
Schedule, Manual, Motion Detection and Sensor
Playback
Channel 124CH Search Mode Time, Event list Backup USB Disk USB2.0 Flash Disk, USB Hard Drive, USB DVD R/W
Browser
IE Browser CMS Yes User Access 10 Users online with professional authority management
Alarm Input
No
Alarm Output
YES
Storage Hard Drive
8 X SATA HDD supports up to 16 TB PTZ
Communication port
1 X RS485 port, support PELCO-P
Power Supply
DC12V 3A
Protocol
PTZ Control Pan, Tilt, Zoom, Preset, Cruise and Trace Ethernet 10/100 MPS Ethernet (RJ-45) Protocol TCP/IP. DHCP. DDNS. NTP and SMTP
Operating Temperature
(-10°C to +55°C) Humidity 10% ~ 90% Humidity
Dimensions
L X W X H (DVR) 260mm X 190mm X 43mm
Weight
KG 1.3KG
