CMOS
1/2.8" Progressive Scan CMOS
RESOLUTION
3072 × 1728 @30fps
LENS
2.8/4 mm fixed lens
AUDIO
Audio I/O: 1 built-in mic, mono sound
ADDITIONAL FEATURE
H.265+, H.265, H.264+, H.264 , IP66
Image Sensor
Min. Illumination
Color: 0.01 Lux @(F1.2; AGC ON), 0.028 Lux @(F2.0; AGC ON)
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
Wide Dynamic Range
DWDR
Focal Length
2.8/4 mm
FOV
2.8 mm, horizontal FOV: 114°, vertical FOV: 62°, diagonal FOV: 135° 4 mm, horizontal field of view: 86°, vertical FOV: 46°, diagonal FOV: 102°
IR Range
Up to 100 meter
Wavelength
850nm
Video Compression
Mainstream: H.265/H.264 Sub-stream: H.265/H.264/MJPEG
Audio Compression
G.711/G.722.1/G.726/MP2L2/PCM
Audio Sampling Rate
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Max. Resolution
3072 × 1728
Image Settings
Saturation, brightness, contrast and sharpness are adjustable via client software and web browser
Network Storage
Support built-in microSD/SDHC/SDXC card (128G), local storage and NAS (NFS, SMB/CIFS), ANR
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, UDP, Bonjour
Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 & DEPEND
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Communication Interface Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage
Built-in microSD/ SDHC /SDXC slot, up to 128 GB
Operating Conditions
Minus 30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, Φ 5.5 mm coaxial plug power
Power Consumption and Current
12 VDC, 0.4 A, Max: 4.8W
Material
Front cover: plastic, camera body: metal
Dimensions
Camera: 69.7 mm × 67.9 mm × 171.4 mm (2.7" × 2.7" × 6.7") With package: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
Weight
Camera: 372g (0.8lb) with package: 659g(1.5lb)
