CMOS
1/3" Progressive Scan CMOS
RESOLUTION
3072 × 1728 @30fps
LENS
2.8/4 mm fixed lens
AUDIO
Audio I/O: 1 built-in mic, mono sound
ADDITIONAL FEATURE
H.265+, H.265, H.264+, H.264, IP66
Image Sensor
Min. Illumination
0.05Lux @ (F1.2, AGC ON) in the color mode and 0.01Lux @ (F1.2, AGC ON) in B/W mode, 0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
Wide Dynamic Range
120dB
Wavelength
850nm
Max. Resolution
3072 × 1728
Image Settings
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser and AGC
Network Storage
NAS (Support NFS, SMB/CIFS), ANR
Protocols
NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, ARP Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering
Client
iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500 & DEPEND
Web Browser
IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port
On-board Storage
Built-in microSD/SDHC/SDXC slot, up to 128 GB
Operating Conditions
Minus 30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply
12 VDC ± 25%, Φ 5.5 mm coaxial plug power
Power Consumption and Current
12 VDC, 0.4 A, Max: 4.8W
Material
Front cover: plastic, camera body: metal
