Signal input
4-128 no. independent network interfaces for a built-in switch
Camera input
up to 128 input
Video input
8 MP/5 MP/4 MP HDTVI video input and live view
Signal
max. 800m for 1080p and 1200m for 720p HDTVI signal
IP video input
Up to 128 input
Incoming bandwidth
Up to 80 Mbps
Decoding resolution
8 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Frames
200/240FPS @ HD1, 100/120FPS @ D1
Recording Mode
Schedule, Manual, Motion Detection and Sensor
Playback
Channel 124CH Search Mode Time, Event list Backup USB Disk USB2.0 Flash Disk, USB Hard Drive, USB DVD R/W
Browser
IE Browser CMS Yes User Access 10 Users online with professional authority management
Alarm Input
No
Alarm Output
YES
Storage Hard Drive
8 X SATA HDD supports up to 16 TB
Communication port
1 X RS485 port
Serial Interface
1 RS-485 half-duplex interface USB interface 2 × USB 2.0 Alarm in / out 4 / 1 (optional)
Power Supply
12 VDC Consumption ≤ 10 W (without hard disk)
Network Interface
Network interface 1 RJ-45 10 / 100 / 1000 Mbps self-adaptive Ethernet interface Built-in switch network interface(DS-7604/08NISE/N supported) 4 independent 10 /100Mbps Ethernet interfaces 8 independent 10 /100 Mbps Ethernet interfaces
Operating Temperature
(-10°C to +55°C) Humidity 10% ~ 90% Humidity
Dimensions
(W × D × H) 315 × 230 × 45mm 445 × 290 × 45mm
Weight
≤ 2 Kg ( without hard disk)
